• Extreme Power and Performance – Handles 500W RMS and 1000W peak power, delivering deep, controlled mid-bass with outstanding clarity and impact.
• Kevlar-Reinforced Paper Cone – Designed for precision and durability, this cone enhances sound accuracy while resisting wear and tear from heavy bass.
• 3" High-Temperature TIL Voice Coil – Built to withstand intense heat and high power levels, ensuring reliable performance even during extended use.
• Die-Cast Aluminum Basket for Stability – Provides a rigid, lightweight structure that reduces resonance and distortion, allowing for cleaner, more dynamic audio.

10"  500W RMS 8-Ohm 3" Voice Coil Audiopipe APLMB Series Loudspeaker

This Listing Includes:

• (1) 10" 500W RMS 8-Ohm 3" VC Loudspeakers

The APLMB-10 mid-bass loudspeaker is engineered for high-performance audio, delivering rich and powerful low tones with exceptional clarity. With a 1000W peak power and 500W continuous power, this speaker provides robust and dynamic sound output. Featuring a 3" high-temperature TIL voice coil, a Kevlar fiber-embedded paper cone, and a 75 Oz magnet, it ensures durability, efficiency, and precision sound reproduction. The die-cast aluminum basket enhances structural strength while isolating internal air for distortion-free performance.

Features:

• Extreme Power and Performance – Handles 500W RMS and 1000W peak power, delivering deep, controlled mid-bass with outstanding clarity and impact.


• Kevlar-Reinforced Paper Cone – Designed for precision and durability, this cone enhances sound accuracy while resisting wear and tear from heavy bass.


• 3" High-Temperature TIL Voice Coil – Built to withstand intense heat and high power levels, ensuring reliable performance even during extended use.


• Die-Cast Aluminum Basket for Stability – Provides a rigid, lightweight structure that reduces resonance and distortion, allowing for cleaner, more dynamic audio.

Specifications:

• Power Handling: 500W


• Peak Power : 1000W


• Impedance: 8 Ohms


• Voice Coil: 3 inches


• Voice Coil Former Material: TIL


• Frequency Response: 60Hz - 7,000Hz


• Sensitivity: 95dB


• Magnet Weight: 75 Oz Ferrite


• Surround: Cloth


• Basket: Die-cast Aluminum


• Winding Material : CCAW


• Cone: Kevlar Fiber Embedded Paper

Measurements:

• Front Mount Baffle Cutout: 9 inches


• Mounting Depth: 4.3 inches


• Overall Diameter: 10.3 inches


• Overall Depth : 4.9 inches


• Motor Diameter : 7.5 inches
