• Pre-loaded DS18 IXS10.4D 10 inch shallow subwoofer rated 600W RMS / 1200W MAX
• Vehicle-specific fit for 4-door Can-Am Maverick X3 2017–2026 rear passenger side
• Sealed under-seat enclosure delivers tight, hard-hitting bass in compact spaces
• Off-road ready design is water-resistant and vibration-resistant for extreme terrain
• Expandable bass system pairs with front and rear enclosures for full-cabin coverage

10" 600W RMS Under-Seat Sub Enclosure Can-Am Maverick X3 4-Door Rear Passenger

This Listing Includes:

• (1) Rear passenger-side under-seat sealed subwoofer enclosure


• (1) Pre-installed DS18 IXS10.4D 10 inch shallow-mount subwoofer

Complete the rear soundstage of your Can-Am Maverick X3 with the DS18 CA-X3BASS10LD/PB. Designed specifically for the rear passenger-side under-seat location on 4-door Maverick X3 models from 2017 to 2026, this enclosure delivers deep, punchy bass while maintaining a clean, factory-style fit.

This enclosure comes pre-loaded with the DS18 IXS10.4D 10 inch shallow-mount subwoofer, rated at 600 watts RMS and 1200 watts max. Tuned for sealed enclosures and tight under-seat spaces, it provides strong low-end output that keeps rear passengers fully immersed without overpowering the rest of the system.

Built for off-road conditions, the enclosure features a sealed, water-resistant, and vibration-resistant design that holds up to dust, moisture, and rough terrain. It mounts securely under the rear passenger seat and stays locked in place even during aggressive riding.

The CA-X3BASS10LD/PB is part of DS18’s full-cabin bass solution for the Maverick X3. Pair it with the rear driver-side enclosure and add the front driver and passenger enclosures to create a complete four-enclosure setup that surrounds every seat with powerful, balanced bass.

Specifications:

• Vehicle Fitment: 4-Door Can-Am Maverick X3 (2017-2026)


• Mounting Location: Rear passenger-side under seat


• Enclosure Type: Sealed under-seat subwoofer enclosure


• Subwoofer Included: DS18 IXS10.4D 10 inch shallow-mount


• RMS Power Handling: 600 Watts


• Max Power Handling: 1200 Watts


• Construction: Water-resistant, vibration-resistant off-road design


• Material: Rotomolded polyethylene enclosure with steel mounting hardware

Subwoofer Specifications (Pre-Installed DS18 IXS10.4D):

• The enclosure comes factory-loaded with the DS18 IXS10.4D 10 inch shallow-mount subwoofer, engineered for high output in compact spaces and ideal for under-seat applications.


• Subwoofer Model: DS18 IXS10.4D


• Nominal Diameter: 10 inch (254 mm)


• Voice Coil Configuration: Dual 4 Ohm (4 + 4 Ohm)


• RMS Power Handling: 600 Watts


• Maximum Power Handling: 1200 Watts


• Sensitivity: 84 dB (1W/1m)


• Frequency Response: 20 to 800 Hz


• Recommended Low Pass Crossover: 90 Hz

Motor and Build Details:

• Voice Coil Diameter: 2.5 inch


• Voice Coil Former: Aluminum


• Winding Material: Copper


• Cone Material: Paper


• Dust Cap Material: Fiberglass


• Surround Material: Stitched Rubber


• Basket Material: Aluminum


• Basket Finish: Corrugated Black


• Magnet Type: Ferrite


• Magnet Weight: 62 oz


• Displacement Volume: 0.9 L / 0.032 ft

Thiele and Small Parameters:

• Fs: 38 Hz


• Qts: 0.816


• Vas: 18.67 L / 0.66 ft


• EBP: 37.9

Recommended Enclosure Performance:

• Minimum Sealed Volume: 14.2 L / 0.5 ft


• Sealed Enclosure F3: 44 Hz

Dimensions:

Designed for OEM under-seat fitment on rear passenger side of 4-door Maverick X3 models
