15" Quad Stack 3000 Watt RMS Dual 4-Ohm Voice Coil Subwoofer DS18 EXL-TRX1534D
15" Quad Stack 3000 Watt RMS Dual 4-Ohm Voice Coil Subwoofer DS18 EXL-TRX1534D
This listing includes:
- (1) DS18 EXL-TRX15.4D Subwoofer
Shake any venue with the EXL-TRX15.4D, a 15” subwoofer designed for epic bass frequencies. Transform your setup with deep, thunderous bass and an instant boost in sound quality from this subwoofer.
The EXL-TRX15.4D delivers massive power with ratings of 6000W MAX and 3000W RMS for ground-shaking bass that instantly boosts your system’s quality. Its advanced thermal management systems ensures consistent performance, even during intense listening sessions. The reinforced non-pressed paper cone with epoxy coating provides unmatched durability, while the dual 4" voice coils optimize your subwoofer’s sound reproduction.
Engineered to dominate, the EXL-TRX15.4D is made for stunt walls and turbo boxes: but, is versatile enough to fit into both sealed (1.25 ft³) and ported (2.5 ft³) enclosures.  It’s 4-ohm impedance and 86dB sensitivity allows the EXL-TRX15.4D converts power into high-impact bass easily. Feel the thunder across a perfect frequency response range of 10 – 400 Hz for a full-bodied audio experience.
The EXL-TRX15.4D is perfect for car audio enthusiasts, competition sound system builders, and anyone who wants concert-like bass in their vehicle. Its robust construction, featuring an aluminum basket and ferrite magnet, ensures long-lasting performance even under intense use.
Upgrade with the EXL-TRX15.4D today and experience bass like never before.
Features:
- Improved Heat Dissipation: Yes
- Cone Shape: Curvilinear
- Speaker Terminals: Push 6ga
Specifications:
- Nominal Diameter: 15" / 381mm
- Nominal Impedance: 4+4 ohms
- RMS Power Handling: 3000W
- MAX Power Handling: 6000W
- Sensitivity (1w/1m): 86dB
- Frequency Response: 10-400 Hz
- Recommended Lo Pass Crossover: 120 Hz
- Voice Coil Diameter: 4" / 99.8mm
- Voice Coil Former Material: Black Aluminum
- Winding Material: CCAW
- Cone Material: Non-Pressed Paper + Epoxy Coating
- Dust Cap Material: PPI
- Surround Material: Foam
- Spider Diameter: 8.5" / 215mm
- Leads Connection Type: Crossed Spider
- Basket Material: Aluminum
- Basket Color/Finish: Black
- Magnet Material: Ferrite
- Magnet Weight: 4 x 98.3 Oz (393 Oz)
- Displacement Volume: 3.82L / 0.134ft3
T/S Parameters:
- Equivalent Volume Vas: 33.9L / 1.197ft3
- Excursion (one way) Xmax: 25 mm
- Free Air Resonance Fs: 50 Hz
- Mechanical Factor Qms: 4.714
- Electrical Factor Qes: 0.855
- Total Factor Qts: 0.724
- Moving Mass Mms: 394.006 g
- Compliance Cms: 0.0343u m/N
- Bl Factor BI: 29.243
- Voice Coil Inductance Le: 9.04 mH
- Diaphragm Area Sd: 844.960 cm2
- Dc Resistance Re: 3.6+3.6 ohms
- Efficiency Bandwidth Product EBP: 49
Recommended Enclosures:
- Sealed Internal Volume: 35.4L / 1.25ft3
- Sealed Box Output Response: 45Hz
- Ported Internal Volume: 70.8L / 2.5ft3
- Port Size *Square (WxHxLong): 2.47"x15"x37" / 62.7x381x939.8mm
- Port Tunning Frequency: 30Hz
- Ported Box Output Response: 26.5Hz
Measurements:
- Overall Diameter: 15.6" / 398mm
- Overall Depth: 11.5 / 293mm
- Front Mount Baffle Cutout: 14" / 355mm
- Mounting Depth: 9.75" / 247mm
- Motor Diameter: 9.1" / 232mm
