• Nominal Diameter: 12
• Nominal Impedance: 2+2 Ohm
• MAX Power Handling: 7000 Watts
• RMS Power Handling: 3500 Watts

Deaf Bonce Car Audio 12 Subwoofer 7000 Watt Dual 2 Ohm VC Apocalypse 3512R-D2

This listing includes:

• (1) Deaf Bonce 12 Competition Subwoofer DB-3512R-D2

The 2022 DB-R series is an upgrade to Deaf Bonce's legendary championship line of subwoofers, thanks to which their team set more than a dozen world records. These subwoofers have high overload capacity and are ready to work continuously at power varied from 2800 watts in everyday musical systems and up to an incredible 25 000 watts of short-term power in competition audio systems.

Disclaimer: Please note that these subwoofers are not covered by warranty in the event of failure and can only be repaired using recone kits. Any damage resulting from misuse, over-powering, or improper installation will not be covered under warranty. We recommend proper handling and installation to prevent damage to the subwoofers. Thank you for your understanding.

SPECIFICATIONS:

• Nominal Diameter: 12


• Nominal Impedance: 2+2 Ohm


• MAX Power Handling: 7000 Watts


• RMS Power Handling: 3500 Watts


• SPL: 86.8dB

MOTOR:

• Voice Coil Diameter: 3.5


• Cone Material: Carbon


• Surround Material: Foam


• Frame Material: Aluminum


• Basket Color: Black


• Magnet Material: Ferrite

THIELE & SMALL PARAMETERS:

• Equivalent Volume: Vas - 28.90L


• Excursion: X-max - 22.5mm


• Eminence: Xmech - 45mm


• Free Air Resonance: Fs - 32.50Hz


• Total Factor: Qts - 0.39


• Force Factor: BL - 24.80

DIMENSIONS:

• Cutout Diameter: 11.18 (284mm)


• Mounting Depth: 9.6 (244mm)
