• Unrivaled Audio Performance - DS18 PRO-D22Ti.8 offers unmatched sound projection with a 2" throat diameter.
• Seamless Integration - With 8 Ohms impedance and 640W peak power handling, it effortlessly integrates into demanding audio setups.
• Crystal-Clear Highs - Titanium diaphragm and 2" voice coil ensure exceptional accuracy for crystal-clear highs.
• Robust Ferrite Magnet - Equipped with a 35 oz ferrite magnet for enhanced efficiency and precise control over sound output.
• Durable Construction - Aluminum body, black/machined finish, and 10UF 100V bass blocker add durability and style.

DS18 2" Throat Bolt-On Compression Driver 320W With Titanium Voice Coil 8-Ohm

This Listing Includes:

• (1) Titanium Voice Coil Compression Driver


• (1) 10UF 100V Bass blocker

Unrivaled Audio Performance with DS18 PRO-D22Ti.8

DS18's PRO-D22Ti.8 stands as the unparalleled choice for those seeking the best from their audio systems. Boasting a 2" throat diameter, it ensures maximum sound projection, covering every corner of the venue. The bolt-on installation type ensures a hassle-free setup, allowing you to focus on achieving impressive volume levels.

Seamless Integration in Demanding Setups

With a nominal impedance of 8 Ohms and an AES power handling capability of 160W, the PRO-D22Ti.8 seamlessly integrates into demanding audio setups. Its program power handling of 320W and peak power handling of 640W guarantee a dynamic and immersive listening experience.

Crystal-Clear Highs with Titanium Diaphragm

The compression driver features a high-quality Titanium 2" voice coil, providing excellent heat resistance and durability for years of reliable performance. The titanium diaphragm delivers crystal-clear highs with exceptional accuracy, ensuring every detail in your music is heard.

Robust Ferrite Magnet for Precise Control

Equipped with a robust ferrite magnet for enhanced efficiency and a magnet weight of 35 Oz, the PRO-D22Ti.8 offers precise control over sound output. The aluminum body adds durability and contributes to reducing unwanted resonance, resulting in cleaner sound reproduction.

Body/Features:

• Filter (Bass Blocker): 10Uf/100V


• Body Material: Aluminum


• Body Color/Finish: Black/Machined

Motor:

• Voice Coil Diameter: 2" / 50.8mm


• Voice Coil Former Material: Kapton


• Winding Material: CCAW (Copper-Clad Aluminum Wire)


• Diaphragm Material: Titanium


• Magnet Material: Ferrite


• Magnet Weight: 35 oz

Speaker Specifications (PRO-D22TI.8):

• SKU: PRO-D22TI.8


• Throat Diameter: 2" / 50.8mm


• Installation Type: Bolt-On


• Nominal Impedance: 8 Ohms


• AES Power Handling: 160W


• Program Power Handling: 320W


• Peak Power Handling: 640W


• Sensitivity (1w/1m): 109dB


• Frequency Response: 630Hz-20KHz


• Recommended Hi Pass Crossover: 800Hz


• Sold in Pair or Single: Single

Measurement:

• Overall Diameter: 5.31" / 135mm


• Overall Depth: 2.08" / 53mm


• Bolt Pattern/Type: 4xM6 - 4" / 102mm
