8" 700W 4 Ohm Pro Car Audio Bullet Midrange Speaker DS18 Series PRO-ZXI8.4BM

This Listing Includes:

• (1) DS18 8" Mid-Range Speaker PRO-ZXI8.4BM

Description:

The DS18 PRO-ZXI8.4BM is a high-performance speaker designed for audio enthusiasts who value both style and sound quality. It features a sleek black basket face with a bullet dust cap, delivering crisp, powerful mid and high-range frequencies. Part of the ZXI series, it combines elegance, clarity, and loudness, making it ideal for those seeking high volume and sound quality without compromising efficiency. With a frequency response of 80Hz to 12.5KHz and a 99dB sensitivity, it offers clean sound with minimal distortion. The lightweight 30 Oz + 3 Oz ferrite magnet and 3.42" mounting depth ensure easy installation and high-power handling.

Specifications:

• Nominal Diameter: 8"


• Nominal Impedance: 4 Ohm


• RMS Power Handling: 350 Watts


• MAX Power Handling: 700 Watts


• Sensitivity (1w/1m): 99dB


• Frequency Response: 80Hz ~ 12.5Khz


• Recommended HI Pass Crossover: 125Hz

Motor:

• Voice Coil Diameter: 1.5"


• Voice Coil Former Material: Glass fiber


• Winding Material: CCAW


• Cone Material: Paper


• Dust Cap Material: N/A


• Bullet Material: Aluminum


• Surround Material: Cloth


• Basket Material: Aluminum


• Basket Color: Black Sandblasted


• Magnet Material: Ferrite + Neodymium


• Magnet Weight: 30 + 3 Oz


• Displacement Volume: 0.63L (0.022ft)

Thiele & Small Parameters:

• Equivalent Volume (Vas): 14.67L (0.512ft)


• Excursion (one way - Xmax): 7.6mm


• Free Air Resonance (Fs): 144Hz


• Mechanical Factor (Qms): 10.07


• Electrical Factor (Qes): 0.823


• Total Factor (Qts): 0.761


• Mechanical Mass (Mms): 5.842g


• Mechanical Compliance (Cms): 0.208mm/N


• BL Factor (BL): 4.478


• Voice Coil Inductance (Le): 0.505mH


• Cone Area (Sd): 224.32cm


• DC Resistance (Re): 3.1 Ohm

Dimensions:

• Overall Diameter: 8.26" (210mm)


• Overall Depth: 3.77" (96mm)


• Front Mount Baffle Cutout: 7" (180mm)


• Mounting Depth: 3.42" (87mm)


• Motor Diameter: 4.72" (120mm)

Weight: 3.5 lbs
