DS18 Elite-Z 12" 1500 Watts Dual Voice Coil 2 Ohm Subwoofer ZR12.2D

The DS18 ZR12.2D is an excellent entry level subwoofer that handles huge power and gives you smooth clean bass. These subs work great in both sealed and ported boxes giving you many options for placement in any vehicle. This 12" model comes in a dual 2 ohm configuration to match your amplifiers optimal impedance. This model comes with a 2.5" voice coil that handles 750 watts RMS and 1500 watts max power. The large foam surround and pressed paper cone work greatly together to deliver smooth crisp bass that can be heard strongly throughout the vehicle.

This Listing Includes:

(1) DS18 12" Subwoofer ZR12.2D

Features:

-Large foam surround for great xmax and bass precision while keeping great cone control when the subwoofer is close to maximum power.

-Great power handling of 750w RMS and 1500w max through a high-strength 2.5" aluminum voice coil.

-Very strong stamped basket with show quality DS18 logos on the frame, magnet boot, magnet, and dust cap.

-Designed to give crisp and clear bass in any vehicle and can be used in sealed and ported boxes.

GENERAL SPECIFICATIONS:

Nominal Diameter: 12"

Nominal Impedance: 2+2 OHMS

RMS Power Handling: 750W

MAX Power Handling: 1500W

Sensitivity (1w/1m): 82 dB

Frequency Response: 25Hz - 200 Hz

Recommended Lo Pass Crossover: 90 Hz

MOTOR SPECIFICATIONS:

Voice Coil Diameter: 2.5" / 61.6mm

VC Former Material: Aluminum

Winding Material: Copper

Cone Material: Non Pressed Paper

Dust Cap Material: PPI

Surround Material: Foam

Basket Material: Steel

Basket Color/Finish: Matte Black

Magnet Material: Ferrite

Magnet Weight: 100 oz

Displacement Volume: 0.07 ft3

THIELE & SMALL PARAMETERS:

Equivalent Volume: 21.2 L

Excursion (one way): 25mm

Free Air Resonance: 26Hz

Mechanical Factor: 4.8

Electrical Factor: 0.84

Total Factor: 0.71

Moving Mass: 299.7g

Compliance: 61.9 m/N

BL Factor: 8.6

Voice Coil Inductance: 567.3m mH

Cone Area: 502.73 Cm2

DC Resistance: 1.8 + 1.8 ohm

Efficiency Bandwidth Product: 30.9

DIMENSIONS:

Overall Diameter 12.44" / 316mm

Overall Depth 7.7"/195.56mm

Front Mount Baffle Cutout 11"/279.43mm

Mounting Depth 6.6"/168mm

Motor Diameter 6.1" / 155mm
