DS18 Hooligan X 12" 6000 Watt 4" DVC 1 Ohm High Excursion Competition Subwoofer

If you are looking for extreme bass and massive earth shaking power, look no further than this Hooligan high excursion subwoofer! This Hooligan will be sure to start you on your way to high volume blasting and massive lows! The DS18 Hooligan X12  has already been proven to provide top end performance and bass now for 6 years on the streets and in the lanes,. Hooligans have been a top  choice of music lovers and competitors alike. This is the latest and greatest revamped revision- the Hooligan X12 High Excursion subwoofer. This model features long throw pole, larger spider, and high excursion surround to lower the FS of the speaker making it louder at subsonic frequencies. This subwoofer is rated at 4000w RMS and 6000w max so your vehicle will require electrical upgrades and large wire. This sub will be friendly to 4th orders, 6th orders, ported boxes, and large sealed boxes and can be used in most applications that has room for the box. With a 50mm one way XMAX, this sub is sure to pump out extreme decibels with the proper power and box setup. We recommend a tuning of 25-30hz for ported boxes depending on your goals. This sub is ready and able for the competition circuit!

This Listing Includes:

(1) DS18 Hooligan 12" Subwoofer

Features:

-High powered 4" Black Aluminum voice coil handling 4000w RMS and 6000w max power for heavy hitting competition bass.

-Huge 500oz magnet will help the voice coil receive and handle the massive power this sub requires with high efficiency and durability.

-Large high excursion surround to help with the high pole to pole flex this subwoofer has giving it has a 50mm one way xmax!

-Larger spider that helps lower the FS (Resonant Frequency) so this sub plays lower much louder than previous versions.

-DS18 Tooled Black basket is one of the slickest and best looking baskets on the market. Not only extremely strong but looks great so you

 can use plexiglass or mount inverted on your box to see the show quality frame and motor topped off by a carbon fiber dust cap.

GENERAL SPECIFICATIONS:

Nominal Diameter- 12"

Nominal Impedance- 1 + 1 Ohm

RMS Power Handling- 4000W

MAX Power Handling- 6000W

Sensitivity (1w/1m)-87 dB

Frequency Response- 20Hz-500Hz

Recommended Lo Pass Crossover- 80Hz

MOTOR SPECIFICATIONS:

Voice Coil Diameter- 4" / 99.8mm

VC Former Material- Black Aluminum

Winding Material- CCAW

Cone Material - Non-Pressed Paper

Dust Cap Material- Carbon Fiber

Surround Material- Foam

Basket Material- Aluminum

Basket Color and Finish- Glossy Black with Machined Aluminum

Magnet Material- Ferrite

Magnet Weight- 500 Oz

Displacement Volume- 4.8L / 0.169 ft3

THIELE & SMALL PARAMETERS:

Equivalent Volume- Vas 23.22 L /.82 ft3

Excursion (one way)- Xmax 50 mm

Free Air Resonance- Fs  26 Hz

Mechanical Factor- Qms 2.65

Electrical Factor- Qes  0.476

Total Factor- Qts  0.444

Mechanical Mass- Mms 554.22g

Mechanical Compliance- Cms  0.069 mm/N

BL Factor- BL 24.65

Voice Coil Inductance- Le  43.12 mH

Diaphragm Area- 471.44 Cm2

DC Resistance- 0.9 + 0.9 Ohm

Efficiency Bandwidth Product- 54.6

RECOMMENDED ENCLOSURES:

Sealed Internal Volume-17L / 0.6 ft3

Sealed Box Output Response-41 Hz

Ported Internal Volume-42.5L / 1.5 ft3

Port Size *Square (WxHxL)-1.52" x 12.28" x 31.82"

Port Tunning Frequency-30 Hz

Ported Box Output Response-25 Hz

DIMENSIONS:

Overall Diameter-12.64"

Overall Depth-11.6"

Front Mount Baffle Cutout-11.2"

Mounting Depth 10"

Motor Diameter 9.96"
