DS18 Car Audio 12" Mid-Bass Loudspeaker 3000 Watt 4 Ohm PANCADO PRO-1.5KP12.4

The Pancadao from DS18 has new siblings to compliment anyone's high-performance pro audio system! These high-performance "do all" woofers can play an amazing range of frequencies. From hard-punching midbass to mid-high vocals at an unbelievable volume. These are the go-to DS18 Pro Audio speakers to set your sound above the rest.

This Listing Includes:

(1) DS18 12" Mid-Bass Loudspeaker PRO-1.5KP12.4

Features:

- Red Color Aluminum Basket with Cloth Edge

- Non-Pressed Paper Cone

- High Temperature CCAW Voice Coil

- 150 Oz High-Strength Ferrite Magnet

SPECIFICATIONS:

Nominal Diameter: 12"

Nominal Impedance: 4 Ohms

RMS Power Handling: 1500 Watts

MAX Power Handling: 3000 Watts

Sensitivity (1w/1m): 96dB

Frequency Response: 60Hz-8KHz

Recommended Hi Pass Crossover: 70Hz

Grill Included: No

MOTOR:

Voice Coil Diameter: 4"

Voice Coil Former Material: Fiber Glass

Winding Material: CCAW

Cone Material: Paper

Dust Cap Material: Paper

Surround Material: Cloth

Basket Material: Aluminum

Basket Color: Black

Magnet Material: Ferrite

Magnet Weight: 150 Oz

THIELE & SMALL PARAMETERS:

Equivalent Volume: Vas - 23.29 L

Free Air Resonance: Fs - 61.6Hz

Mechanical Factor: Qms - 6.905

Electrical Factor: Qes - 0.388

Total Factor: Qts - 0.388

Mechanical Mass: Mms - 184.02g

Mechanical Compliance: Cms - 60.952 mm/N

BL Factor: BL - 15.144

Voice Coil Inductance: Le - 1.566MH

Cone Area: Sd - 560 cm

DC Resistance: Re - 3 Ohm

Efficiency Bandwidth Product: EBP - 158

MEASUREMENTS:

Overall Diameter: 12.36" (314mm)

Overall Depth: 6.53" (166mm)

Front Mount Baffle Cutout: 11.18" (284mm)

Mounting Depth: 5.98" (152mm)

Motor Diameter: 8.66" (220mm)
