• Superior Mid-Range Performance: The DS18 PRO-GM6SE delivers clear and detailed mid-range frequencies, making it ideal for handling vocals and instrument fundamentals.
• Professional Grade Design: Featuring a paper cone, cloth surround, and Kapton voice coil former, this loudspeaker ensures low-distortion reproduction for faithful sound reproduction.
• Versatile Configuration: Choose between classic, bullet, or sealed back options to suit your audio setup preferences.
• High Power Handling: With a maximum power handling of 480 Watts and RMS power handling of 140 Watts, this loudspeaker delivers powerful and dynamic sound.
• Premium Construction: Built with a matte black steel basket and ferrite magnet, this loudspeaker offers durability and reliability for long-term use.

DS18 6.5" 480W Max 8-Ohm Sealed Back Mid Range Loudspeaker PRO-GM6SE

This Listing Includes:

• (1) 480W Sealed Mid Range Loudspeaker

Experience unparalleled mid-range performance with the DS18 PRO-GM6SE 6.5" Loudspeaker. Designed to handle vocals and instrument fundamentals with clarity and depth, this loudspeaker is a testament to DS18's commitment to quality audio reproduction. The PRO-GM series midranges, derived from the acclaimed GEN Series, have been meticulously tweaked to perfection. Featuring a paper cone, cloth surround, and Kapton voice coil former, this loudspeaker ensures low-distortion reproduction for faithful sound reproduction. Choose between classic, bullet, or sealed back configurations to match your audio setup preferences. With a maximum power handling of 480 Watts and RMS power handling of 140 Watts, this loudspeaker delivers powerful and dynamic sound for an immersive listening experience.

Features:

• Clear and detailed mid-range performance


• Paper cone and cloth surround for low-distortion reproduction


• Kapton voice coil former for enhanced durability


• Versatile classic, bullet, or sealed back configurations


• High power handling for powerful and dynamic sound


• Matte black steel basket and ferrite magnet for durability and reliability

Technical Specifications:

• Nominal Diameter: 6.5" (165.1mm)


• Nominal Impedance: 8 Ohms


• RMS Power Handling: 140 Watts


• Max Power Handling: 480 Watts


• Sensitivity (1w/1m): 93 dB


• Frequency Response: 315Hz ~ 10kHz


• Recommended Hi Pass Crossover: 400Hz


• Voice Coil Diameter: 1.5" (38.1mm)


• Cone Material: Paper


• Surround Material: Cloth


• Basket Material: Steel


• Magnet Material: Ferrite


• Magnet Weight: 23 Oz

Thiele & Small Parameters:

• Equivalent Volume: Vas - 0.48L / 0.017ft


• Free Air Resonance: Fs - 457 Hz


• Mechanical Factor: Qms - 7.744


• Electrical Factor: Qes - 3.592


• Total Factor: Qts - 2.454


• Mechanical Mass: Mms - 6.187g


• Mechanical Compliance: Cms - 0.02mm/N


• BL Factor: BL - 5.54


• Voice Coil Inductance: Le - 0.689mH


• Cone Area: Sd - 132.73cm


• DC Resistance: Re - 6.2 Ohms

Measurements:

• Overall Diameter: 6.57" (167mm)


• Overall Depth: 2.7" (69mm)


• Mounting Depth: 2.5" (64mm)


• Motor Diameter: 4.33" (110mm)
