• True 1/0 AWG Specifications: Made in the USA with precise true AWG standards for reliable performance.
• Wide Temperature Range: Operates from -50°C (-50°F) to 105°C (221°F), suitable for extreme environments.
• Industry Approvals: Meets UL 2556, UL 558, UL 583, UL 4127, and SAE J1127 standards, and is REACH, RoHS, CMRT, and Prop 65 compliant for safety and reliability.
• High-Quality Conductors: Rope-lay, bunch-stranded SAE copper conductor with 975 strands of 30 AWG copper for superior conductivity.

GP Car Audio 1/0 True AWG Welding Copper Power/Ground Wire Red Lot

This listing is for 1/0 AWG Welding Copper wire (Red) sold by the foot or hand cut and rolled into 5 foot, 10 foot, 20 foot and 50 foot increments. If you purchase a quantity of 100ft you will get one complete roll.

Bulk Increments:

• True Spec's 1/0 AWG USA made welding wire

Conductors:

• Rope-lay, Bunch-stranded 30 AWG SAE copper conductor


• Strand Count: 975 (30 GA Strands)

Insulation & Jacket:

• Wrapped paper separator


• Jacketed with proprietary low-smoke, halogen-free EPDM compound


• Resistant to abrasion, battery acid, diesel fuel, engine oil, ethanol, extreme temperatures, flame, gasoline, power-steering fluid, transmission fluid


• Insulation thickness: .080" (2.03m)


• Overall outside diameter thickness: 0.533" (13.54mm)

Temperature Range:

• -50C (-50F) to 105C (221F)

Industry Approvals:

• UL 2556


• Meets battery cable requirements per:


• UL 558 and UL 583


• UL 4127 (60 V DC; 25 V AC)


• SAE J1127 Compliant


• REACH, RoHS, CMRT, and Prop 65 Compliant
