• Basket: Heavy Gauge Steel with Industrial Texture Painting
• Magnets: Dual Stacked High Flux Y0 120oz Strontium Ferrite
• Voice Coil: 2.5" 4-Layer Hi-Temp Copper, Dual Impedance
• Spider: Poly Cotton with Woven Round Tinsel Leads
• Cone: UV Treated / Non-Pressed Paper Cone with EROM Foam Surround
• Gasket & Boot: Customized Rubber Gasket & Magnet Boot

Massive Audio 12" 800 Watts RMS 36 Hz 2.5" Dual 2 Ohm Subwoofer GTX122H

This Listing Includes

• (1) 12" 800 Watts RMS 36 Hz 2.5" Dual 2 Ohm Subwoofer

Our GTX122H Series subwoofers are rated at 800 watts RMS / 1600 watts MAX power with a 2.5" voice coil configured for Dual 4 ohm impedance. All GTX subs use tight Red stitching that’s sewn through a UV treated non-pressed paper cone onto a Pressed Foam surround. Then it’s bonded to a heavy gauge steel basket that’s bolted to double stacked high flux Y30 120oz Strontium ferrite magnets with a 10mm top plate. Then everything dances on a springy poly cotton spider with high powered woven tinsel leads that connect to spring loaded 5-way binding nickel plated speaker connectors.

Key Features

• Basket: Heavy Gauge Steel with Industrial Texture Painting


• Magnets: Dual Stacked High Flux Y0 120oz Strontium Ferrite


• Voice Coil: 2.5" 4-Layer Hi-Temp Copper, Dual Impedance


• Spider: Poly Cotton with Woven Round Tinsel Leads


• Cone: UV Treated / Non-Pressed Paper Cone with EROM Foam Surround


• Gasket & Boot: Customized Rubber Gasket & Magnet Boot

Specifications

• Size: 12"


• Watts RMS: 600-800 Watts


• Peak Power: 1600 Watts


• Cone: Non-Pressed Paper


• Voice Coil: 2.5" Dual 2 Ohm


• Magnet: 120oz


• Terminals: 5 Way Binding Push Terminals


• Basket: Heavy Gauge Steel


• Tinsel Leads: Woven Round


• X-Max: 15mm with 10mm Top Plate


• SPL: 88 dB


• FS: 36Hz


• Ported Box: 14"H x 16"D x 16"W / 14.05 sq. in. Port Area


• Sealed Box: 1.62 ft/Cubed


• Mounting Depth: 6.34"


• Cut Diameter: 9.05"


• Overall Diameter: 16.73"
