• 600 Watts Max Power Handling
• 2" Voice Coil
• 96.5 dB Sensitivity
• 135HZ-12.5KHz of frequency response

Resilient Sounds NEO Series 6.5" 300 Watt RMS 4 Ohm Midrange Car Audio Loudspeaker

This Listing Includes

• (1) 6.5" 300 Watt Midrange Loudspeaker

Features

• 600 Watts Max Power Handling


• 2" Voice Coil


• 96.5 dB Sensitivity


• 135HZ-12.5KHz of frequency response

Specifications

• Nominal Diameter: 6.5" (165mm)


• Max Power Handling: 600 w


• RMS Power Handling: 300 w


• Frequency Response: 135Hz-12.5KHZ


• Nominal Impedance: 4 ohm


• Sensitivity: 96.5dB


• Magnet: Neodymium


• Voice Coil Diameter: 2"


• Voice Coil Wire: CCAW

THIELE-SMALL PARAMETERS

• Equivalent Volume (Vas): 2.75 L


• Free Air Resonance (Fs): 138 Hz


• Mechanical Factor (Qms): 6.53


• Electrical Factor (Qes): 0.35


• Total Factor (Qts): 0.34


• Cone Area (Sd): 136.8cm


• Mechanical Mass (Mms): 12.66 g


• BI Factor (BI): 9.92 Tm


• Dc Resistance (Re): 3.2 Ohms

Dimensions:

• Overall Diameter: 6.69" (210mm)


• Front Mount Baffle Cutout: 5.90" (186mm)


• Mounting Depth: 2.73" (79mm)


• Overall Depth: 3.01" (89.3mm)
