• Peak Power rating of 1000 Watts with 500 Watt RMS
• Frequency range of 50Hz - 5.5KHz for the perfect Mid-Bass range
• 2.5 inch Voice Coil
• Mounting depth: 4.10 inches

Sky High Car Audio 10 Inch 1000W Peak 8 Ohm Midbass Loud Speaker SH-MB10

This listing includes:

• (1) 10 Inch 1000W Peak 8 Ohm Midbass Loud Speaker

Specifications:

• Nominal Diameter: 10 inches


• Nominal Impedance: 8 Ohms


• Peak Power Handling: 1000 Watts


• RMS Power Handling: 500 Watts


• Sensitivity (1w/1m): 98dB


• Frequency Response: 50Hz - 5.5KHz


• Recommended Hi Pass Crossover: 60Hz

Woofer Specifications:

• Voice Coil Diameter: 2.5 inches


• Voice Coil Former Material: USA Fiberglass


• Winding Material: Japan SV


• Cone Material: Paper


• Dust Cap Material: Paper


• Surround Material: Cloth


• Basket Material: Aluminum


• Magnet Material: Ferrite


• Magnet Weight: 68 oz.


• Displacement volume: 1.24L / 0.043ft3

Thiele & Small Parameters:

• Equivalent Volume / Vas: 25.1L / 0.88ft3


• Excursion (one way) Xmax: 11mm


• Free Air Resonance / Fs: 78Hz


• Mechanical Factor / Qms: 8.21


• Electrical Factor / Qes: 0.46


• Total Factor / Qts: 0.435


• DC Resistance / Re: 5.2 Ohms


• Mechanical Mass / Mms: 27.983g


• Mechanical Compliance / Cms: 0.150 mm/N


• BL Factor / BL: 12.4


• Voice Coil Inductance / Le: 17.87 mH


• Cone Area / Sd: 363.07 Cm2


• Mechanical Mass Without Air / Mmd: 34.330g

Dimensions:

• Overall Diameter: 10.27 inches


• Front Mount Baffle Cutout: 9.13 inches


• Mounting Depth: 4.10 inches


• Overall Depth: 4.46 inches


• Motor Diameter: 6.3 inches
