• 750W RMS subwoofer delivers powerful bass with clean controlled output
• Dual 4 ohm 2.5 inch high-temp copper voice coil built for daily power handling
• Class-leading 14mm Xmax for strong low frequency performance without distortion
• Heavy cast aluminum basket with stitched tinsel leads for long-term durability
• Optimized cooling system keeps the sub running cool under high output

Sundown Horizon 10" 750 Watt RMS Dual 4 Ohm Car Audio Subwoofer HZ-10

This Listing Includes:

• (1) Horizon Series HZ-10 Dual 4 Ohm Subwoofer

The HZ-10 from Sundown Audio is built for serious low-end performance in compact and mid-size enclosures. Rated at 750 watts RMS with a high-temperature 2.5 inch copper voice coil and a class-leading 14mm of excursion, this subwoofer delivers deep, controlled bass with impressive efficiency.

A heavy-duty cast aluminum basket, bolted spider pack, and stitched Mini-XL tinsel leads ensure long-term durability even under hard daily use. The high-roll surround paired with a progressive spider keeps movement smooth and accurate, while the vented motor gap and pole piece maintain cool operating temperatures when pushing power.

Optimized for ported enclosures but versatile enough for sealed builds, the HZ-10 is perfect for systems that want loud, clean bass without sacrificing sound quality or reliability.

Specifications:

• RMS Power Handling: 750 Watts


• Voice Coil: 2.5" High Temp 4-Layer Copper


• Impedance: Dual 4 Ohm


• Xmax: 14mm

T/S Parameters:

• Re: 6.13 Ohms


• Fs: 33.143 Hz


• Vas: 22.863 L


• Qes: 0.539


• Qms: 3.430


• Qts: 0.466


• BL: 19.782 NA


• Mms: 165.360 g


• Cms: 139.453 mm/N


• Sensitivity: 83.8 dB @ 1W/1M

Recommended Enclosures:

• Ported: 1.0 cu ft net, 15 sq in port area, tuned to 35 Hz


• Sealed: 0.5 cu ft net


• Displacement: 0.1 cu ft

Dimensions:

• Mounting Depth: 5.8"


• Outside Diameter: 10.45"


• Cutout Diameter: 9.2"
