• 500W RMS compact subwoofer delivers powerful bass in small enclosures
• Dual 4 ohm high-temp 2 inch copper voice coil handles daily power with ease
• Class-leading 14mm Xmax for strong output without distortion
• Heavy cast aluminum basket with stitched tinsel leads for long-term durability
• Optimized cooling system keeps performance consistent during hard play

Sundown Horizon 8" 500 Watt RMS Dual 4 Ohm Car Audio Subwoofer HZ-8

This Listing Includes:

• (1) Sundown Horizon Series HZ-8 Dual 4 Ohm Subwoofer

The HZ-8 from Sundown Audio is built to deliver serious bass from a compact footprint. Rated at 500 watts RMS with a high-temperature 2 inch voice coil and class-leading 14mm Xmax, this subwoofer is designed to move air efficiently while staying controlled and musical.

A heavy-duty cast aluminum basket, stitched tinsel leads, and bolted spider pack give it the strength to handle daily power with ease. The high-roll surround and progressive spider provide smooth excursion, while the vented motor gap and pole piece keep temperatures in check during hard play.

Perfect for small builds that still want real output, the HZ-8 shines in ported enclosures and delivers tight, punchy bass that feels much bigger than its size.

Specifications:

• RMS Power Handling: 500 Watts


• Voice Coil: 2" High Temp 4-Layer Copper


• Impedance: Dual 4 Ohm


• Xmax: 14mm

T/S Parameters:

• Re: 5.8 Ohms


• Fs: 41.323 Hz


• Vas: 7.529 L


• Qes: 0.549


• Qms: 2.997


• Qts: 0.464


• BL: 17.618 NA


• Mms: 113.099 g


• Cms: 131.157 mm/N


• Sensitivity: 81.7 dB @ 1W/1M

Recommended Enclosures:

• Ported: 0.65 cu ft net, 9 sq in port area, tuned to 35 Hz


• Sealed: 0.3 cu ft net


• Displacement: 0.07 cu ft

Dimensions:

• Mounting Depth: 5.28"


• Outside Diameter: 8.6"


• Cutout Diameter: 7.25"
