4-Channel 120W RMS 2-Ohm Class-D Ultra Compact Amplifier DS18 X Series / X4XL
4-Channel 120W RMS 2-Ohm Class-D Ultra Compact Amplifier DS18 X Series / X4XL
This Listing Includes:
- (1) X4XL Amplifier
Description:
DS18’s X4XL delivers audio excellence in an incredibly compact package, perfect for every car audio enthusiast. This powerhouse boasts 1800W peak power, with 4 x 120W RMS at 4 ohms, 4 x 180W RMS at 2 ohms, and 2 x 300W RMS at 4 ohms in bridge mode, providing relentless and powerful sound.
Its sleek, ultra-compact design allows for installation in the tightest spaces without compromising on performance. The X4XL offers versatile crossover settings (LPF/FLAT/HPF) within a comprehensive range of 40Hz-500Hz, along with a 2-channel/4-channel input selector, giving you unparalleled control over your sound.
Combining compact size with robust power, the X4XL features advanced surface mount technology and a stable four-layer PCB design for exceptional durability and performance. It is rugged and reliable, equipped with thermal, overload, and short circuit protection, ensuring your system’s safety and longevity.
Features:
- 4 Channel Full Range
- Class D
- 2 ~ 4 Ohm Stable
- 4 X 120 Watts @ 4 Ohm
- Power / Protect Indicator
- Ultra Compact Design
Specifications:
- SKU: X4XL
- Total Watts (Peak): 1800W
- RMS Power @ 4 ohm: 120W X 4CH
- RMS Power @ 2 ohm: 180W X 4CH
- RMS Power @ 4 ohm Bridge: 300W X 2CH
Audio
- Frequency Response: 20Hz-20KHz
- Signal to Noise Ratio: >90dB
- Efficiency @ 4ohm: >80%
- Damping Factor: >202
- Total Harmonic Distortion (THD): <.10%
- Low Level Input Range: 0.2-5V
- Selectable X-Over: LPF/FLAT/HPF
- X-Over Filter Range: 40Hz -500Hz
Features
- Amplifier Class: Digital
- Amplifier Type: Stereo Full Range
- Number of Channels: 4
- Minimum Impedance: 2 Ohm stereo / 4 Ohm Bridge
- Led Indicator: Power/Protection
- Power Input Terminal Size: 8Ga
- Recommended Fuse Size: 45A
- Thermal Protection: Yes
- Over-Load Protection: Yes
- DC Output Protection: Yes
- Short Circuit Output Protection: Yes
- Voltage Input Protection: Yes
- 2CH/4CH Input Selector: Yes
Measurement
- Overall Length: 7.13" / 181.2mm
- Overall Wide: 3.24" / 82.4mm
- Overall Height: 1.37" / 34.8mm
- Heatsink Length: 6.33" / 160.88mm
