• Versatile 4-Channel Power – 800W RMS @ 2 Ohm for mids, highs, or bridged subwoofer setups.
• Class D Efficiency – Delivers clean sound with minimal heat and power draw.
• Flexible Configuration – Bridgeable channels for custom audio layouts.
• Compact Design – Perfect for motorcycles, ATVs, and tight car installs.
• Brazilian Built – Engineered by Banda, a trusted name in high-performance car audio.

Banda 800 Watt 2-Ohm 4-Ch Pocket Series Compact Brazilian Amplifier BD-800.4-2

This Listing Includes:

• (1) Banda Pocket Series Compact 800 Watt 2-Ohm 4-Channel Brazilian Amplifier BD-800.4-2

Small but powerful - the Banda Pocket BD-800.4-2 is a compact 4-channel amplifier engineered for tight spaces without compromising output. Designed with Banda’s trusted Brazilian tech, this amp delivers up to 800 Watts RMS in a lightweight, ultra-compact footprint. Ideal for mids, highs, or full-range systems, the BD-800.4-2 offers high efficiency, clean signal output, and versatile bridging options to fit nearly any install. Whether you're upgrading a daily driver or building out a custom install, the Pocket Series gives you serious performance in a small package.

Features

• Compact chassis for tight installs


• 4 x 230W RMS @ 2 Ohm (14.4V)


• 2 x 460W RMS Bridged @ 4 Ohm (14.4V)


• Full-range Class D amplifier – great for mids, highs, or full system


• Advanced crossover network with HPF & LPF (Linkwitz-Riley)


• 85dB signal-to-noise ratio for clean audio reproduction


• Wide input sensitivity range: 250mV – 3.4V


• Low THD at full power (<1%)


• Lightweight aluminum housing for heat dissipation and durability

Specifications

• Maximum Power: 4 x 230 WRMS 14.4v @ 2 Ohms


• Maximum Power: 4 x 150 WRMS 14.4v @ 4 Ohms


• Maximum Power: 2 x 460 WRMS 14.4v Bridged @ 4 Ohms


• Maximum Power: 4 x 200 WRMS 12.6v @ 2 Ohms


• Maximum Power: 4 x 120 WRMS 12.6v @ 4 Ohms


• Maximum Power: 2 x 400 WRMS 12.6v Bridged @ 4 Ohms


• Total Power: 800 Wrms @12.6 volts


• Impedance: 2 Ohms


• Input Voltage: 9 - 16V


• Input Impedance: 47K Ohms


• THD maximum power: 1%


• Input Sensitivity: 250mV - 3.4V


• Signal to Noise Ratio: 85dB


• Frequency Response (FLAT Switch): 20Hz - 20Khz (-3dBs)


• Channels: 4


• HPF (Subsonic): 90Hz - 20kHz @ 12dB/oitava Linkwitz-Riley


• LPF (Crossover): 20Hz - 90Hz @ 12dB/oitava Linkwitz-Riley


• Recommended Fuse: 50A Rest Current 700mA


• Maximum Current (sine signal): 80A


• Maximum Current (musical signal): 40A


• Power Cables (min. recommended): 10mm


• Output Cables (min. recommended): 2 x 1,5mm / 2 x 15 AWG

Dimensions

• Weight: 1.9 Lbs


• Height: 2 inches


• Width: 4.6 inches


• Depth: 5 inches

Box Measurements

• Length: 5.5 in


• Width: 4.8 in


• Height: 2.3 in


• Weight: 1.75 lbs
