• Adjustable Regulated Output Voltage: 10V to 16V
• 100 Amp Output: Supports systems up to 1500W RMS
• Linkable Units: Connect up to 4 units for a combined 400 Amp output, supporting systems up to 6000W RMS
• Quad Cooling Fans: Ensures efficient thermal management under heavy loads
• Switching Power Supply: Utilizes modern PWM technology for high efficiency
• 0 Gauge Power Output Terminals: Facilitates seamless integration with existing charging systems
• Protection Features: Includes thermal and current overload protection, as well as current sensing and pulse charging technologies to protect connected batteries from overcharging and inhibit sulfation
• Sleek Amplifier-Style Chassis: Designed for easy integration into mobile installs, test benches, and demo setups

DD Audio 100 Amp 10 - 16 Volt AC/DC Linkable Power Supply SPS-100.4

This Listing Includes

• 1 DD-SPS-100.4 - 100 Amp AC~DC Power Supply


• 1 Voltage Meter


• 1 Power Cord

Product Description

Forget the old-school bricks. Traditional AC to DC linear power supplies are bulky, outdated, and barely scratch the surface when it comes to real power output. The SPS-100.4 flips the script with a high-efficiency switching design powered by advanced PWM tech—giving you serious performance in a sleek, amp-style chassis built for mobile installs, test benches, and demo setups.

Need power when your vehicle’s off? No problem. The SPS-100.4 delivers up to 100 amps at 16V, easily supporting systems up to 1500 watts RMS. Need more juice? Stack up to four units for a massive 400 amps, perfect for pushing 6000-watt builds without breaking a sweat.

And yeah, it’s built to handle the heat—literally. We’re talking beefed-up AC connections and high-quality fusing so you stay powered up and protected, no matter how hard you're pushing your gear.

WARNING: Do not use this product to charge discharged batteries and follow all warnings listed in the manual.

Features

• Adjustable regulated output voltage 10V~16V


• 100 Amp Output


• Link up to 4 units for 400 Amp Output


• Thermal and current overload protection


• Quad Cooling Fans


• Remote mount LCD voltage display


• 0 Gauge Power Output Terminals


• Battery charging mode for Lead Acid, LiFePo4, and other battery chemistries with a max charge voltage of 14.8

Specifications

• Input Voltage: 120V AC


• Output Voltage: 16V DC


• Output Current: Up to 100 Amps


• Power Output: Supports up to 1500W RMS systems (400A combined for 6000W when linking 4 units)


• Technology: Switching power supply with PWM (Pulse Width Modulation)


• Form Factor: Amplifier-style chassis for easy integration into mobile installs


• Expandable: Linkable up to 4 units for high-current applications


• Applications: Ideal for powering audio systems when a vehicle is off, test benches, and mobile displays


• Protection Features:

  Internal short circuit protection

  Thermal overload protection

  Over-voltage protection

  Current limiting


• Cooling: Internal fan for thermal management


• Connections: Upgraded AC power input terminals

  High-quality fusing for stable operation under load

Dimensions:

• Length 10.5


• Width    9.5


• Height   2.5


• Weight  11
