• Marine Powerhouse: DS18 NXL-X1500.1FR delivers 1500W RMS @ 1-Ohm, perfect for marine and powersports applications
• Versatile Performance: Full Range Capabilities empower users to drive subs or mids/highs. Ideal for enhancing audio clarity in any marine build
• Waterproof Design: Boasts an IP67 Waterproof Rating, ensuring protection against water intrusion in harsh marine conditions
• Durable Build: With UV, Salt, and Fog protection, this amp is built to endure nature's challenges without compromising sound quality
• Digital Amplification: Latest digital amplifier design with SMC technology for high pass and low pass filters, offering exceptional clarity

DS18 1 Channel Full Range Class D 1500W RMS 1 Ohm Marine Amplifier NXL-X1500.1FR

This Listing Includes:

(1) NXL 1 Channel Full Range 1500W RMS Marine Amplifier

Description

Elevate your marine sound experience with the DS18 NXL-X1500.1FR. This 1-Channel Class D amplifier delivers an impressive 1500W RMS @ 1-Ohm, making it the ultimate choice for marine and powersports enthusiasts. Designed for versatility, it allows you to power subs or mids/highs, providing unmatched audio clarity. Built to withstand the harshest marine conditions, the NXL-X1500.1FR boasts an IP67 Waterproof Rating, safeguarding against water intrusion. The durable construction includes UV, Salt, and Fog protection, ensuring longevity without compromising on sound quality.

Features

• Waterproof Rating: IP67


• UV / Salt Fog Protection: Yes


• Direct Power Harness Design: Yes


• Quick Connect Plug: Yes


• Amplifier Class: Digital


• Amplifier Type: Full Range


• Number of Channels: 1


• Minimum Impedance: 1 Ohm


• Power | Protection | Clip: 4GA Tinned OFC


• Fuse: 150A


• LED Indicator: Yes (7-16V)

Specifications:

• Frequency Response: 10Hz-250Hz


• Signal to Noise Ratio (1W @ 4?): >81dB


• Efficiency @ 4 ohm: 92%


• Input Impedance: 20K OHM


• Total Harmonic Distortion (THD): <0.05%


• Input Sensitivity: 200mV-5V


• Band-Pass Filters: LPF: 50Hz-20KHz / HPF: 10Hz-500Hz


• Bass Boost: 0-18dB


• Subsonic Filter: 42Hz


• Phase Shift Control: 0-180

Output Power:

• Total Watts (Peak): 3000W


• RMS Power @ 4 ohm: 700W


• RMS Power @ 2 ohm: 1000W


• RMS Power @ 1 ohm: 1500W

Dimensions:

• Overall Length: 13.4"


• Overall Width: 4.4"


• Overall Height: 1.77"
