DS18 Car Audio 4 Channel Class D 1800W Full Range Car Amplifier G1800.4D

The Gen-X series has always been a DS18 staple with the public and been in countless system builds over the many years it was released. We have redesigned the GEN-X series from the ground up to meet audio enthusiasts high standards and complete every goal for the system of their dreams with great power, reliability, and efficiency. The G1800.4D has a power rating of 4x150 watts RMS at 4 ohms 4x230 RMS at 2 ohms, 2x430 at 4 ohm bridge, and 1800 watts MAX at the ohm load it was designed for, giving you pure and clean power on demand. This amp has the power to drive your speakers but also not take up much space because of the new compact design and technology that will keep your amp playing cool and loud. Built with a Small and powerful design so you can power your subs with great efficiency and power without taking up much space .

Listing Includes:

(1) DS18 4 Channel Amplifier G1800.4D

(2) 40 Watt Fuses

(4) Phillip Head Screws

(4) Washers

(4) Spacers

Power Features:

Total Watts (Peak):1800W

RMS Power @ 4 Ohm:4 x150W

RMS Power @ 2 Ohm 4 x230W

RMS Power@ 4 Ohm Bridge: 2 x430W

Audio Features:

Frequency Response:20Hz- 20KHz

Signal to Noise Ratio: Greater than 90 db

Total Harmonic Distortion(Thd):0.01%

Low Level Input Range: 0.25 -6V

Selectable X-Over: LPF/FLAT/HPF

Features:

Amplifier Class : Digital(D)

Amplifier Type: 4CH Full Range

Number of Channels:4 Channel

Minimum Impendence:2 OHM ST/ 4Ohm Bridge

Led Indicator: Power /Protection /Clip

Power Input Terminal Size: 4 GA

Fuse Size:2 x 40A

Thermal Protection: Yes

Over- Load Protection: Yes

DC Output Protection: Yes

Short Circuit Output Protection: Yes

Voltage Input Protection

Clipping protection: Yes

Body Color: Matte Black

Measurement:

Overall Length:12":

Overall Wide 4.72"

Overall Height: 1.96"

Heatsink Legnth:10.15

Weight:1.90
