• Short circuit protection, Over current protection
• Cast aluminum heatsink
• Total Power: 1000 Watts
• Infrasonic filter
• Number of Channels: 5

Rockford Fosgate Punch 5-Channel 1000-Watt Class-BD Amplifier P1000X5

This listing includes:

• (1) P1000X5 5-Channel Amplifier

The P1000X5 1,000 Watt full-range 5-channel is the one-and-only amplifier you will need to run your entire system. Run dash speakers off the front channels, run back speakers off the rear channels and run subwoofer(s) off the 5th channel! Known world-wide for brute power, this amplifier offers a higher level of efficiency along with a tri-stage protection that covers thermal, over-current and short circuits.

Features:

• Number of Channels: 5


• Total Power: 1000 Watts


• Rated Power:


• 75W x 4 + 150W x 1 @ 4 Ohm


• 125W x 4 + 300W x 1 @ 2 Ohm


• N/A + 500W @ 1 Ohm


• High level input capable with Auto Turn-On circuit


• Features C.L.E.A.N. Set-up


• Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)


• 12dB/octave Butterworth crossover


• On-board Punch EQ with +18dB boost @ 45Hz


• Muted turn on


• Stealth top mounted control panel


• Cast aluminum heatsink


• Short circuit protection


• Over current protection


• Infrasonic filter


• 2/4 channel input switch


• 1 Year Warranty

Dynamic Power:

• 115W x 4 + 299W x 1 @ 4 Ohm


• 190W x 4 + 540W x 1 @ 2 Ohm


• N/A + 863W x 1 @ 1 Ohm


• Frequency Response: Front/Rear: 20Hz - 20kHz +/-3dB


• Sub:20Hz - 500Hz +/-3dB


• Input Sensitivity: 150 mV - 12 V


• Efficiency: Front / Rear: 66% @ 4 Ohm


• Sub Channel: 80% @ 4 Ohm

Dimensions:

• Length: 15.03" / 38.18cm


• Width: 7.76" / 19.71cm


• Height: 2.38" / 6.05cm
