DD Audio Digital Designs 6x9" 300W 4-Ohm Midrange Speakers VO-M6X9B-S4

This listing includes:

(2) 6x9" 300W 4-Ohm Midrange Speakers

The DD VO-M6x9b drivers represent a hybrid fusion of Hi Fidelity and Hi-end Pro Audio innovations, integrating specially engineered components for high sensitivity/output and minimal distortion. These drivers utilize long fiber pressed cones crafted from water-resistant synthetic resin to achieve both high rigidity and ultra-light moving mass, crucial for elevated sensitivity and extended upper-frequency response. The curvilinear cone profile ensures a seamless frequency response into the upper octaves. With high-energy ferrite motors, inductance-reducing shorting rings, non-inductive coil formers, and CCA wire, the VO-M drivers eliminate electromagnetic distortion, delivering clear, clean, and crisp performance across the midbass, vocal, and high-frequency range. Their output capability is well-suited for handling substantial subwoofer systems or challenging high-noise environments. Elevate your audio experience with the precision and clarity of the DD VO-M6x9b drivers.

Features:

• Kapton Voice Coil Former for Decreased Inductance


• Moisture Resistant Polymer Infused Curvilinear Cone


• M-Roll Surround for Increased Midbass Response


• CCA Voice Coil Wire for Increased Efficiency

Specifications:

• Speaker Size (In):6 x 9


• Watts RMS: 100


• Watts Peak: 300


• Impedance: S2 / S4


• VCD (In): 1.5


• Frequency Response (Hz): 80 - 8k


• Fs (Hz): 75


• Qms: 1.6


• Qes: 0.42


• Qts: 0.33


• Vas (Liters): 6.1


• dBSPL: 94


• Mounting Diameter (In): 8.7 x 5.9


• Mounting Diameter (MM): 220 x 150


• Overall Diameter (In): 9.29 x 6.45


• Mounting Depth (In): 3


• Mounting Depth (MM): 77


• Overall Depth (In): 3.14
