• Customizable crossovers - Butterworth, Linkwitz-Riley, and Bessel, with attenuations from 6dB/8a to 48dB/8a for tailored audio.
• Precision equalization - 15 bands between 1/3 octave on the input equalizer and 3 independent bands per channel on the parametric equalizer.
• Versatile features for audio customization - 2 RCA inputs, 8 independent outputs, and routing channels.
• User-friendly with preconfigured settings - user-controlled password, pink-noise generator, and out-of-the-box convenience.
• Advanced functions for precision control - independent delay, limiter function with threshold, attack, and decay.

Marts Digital Chatturat-8.2 8 Channel DSP With 15 Band Crossover DSP-8

This listing contains:

• (1) Marts Digital DSPW/ 8 Ch Equalizer 15 Band CHATTURAT-8.2

Marts CHATTURAT-8.2 8-Channel Equalizer DSP:

Embark on a sonic journey into the universe of high-performance audio with Marts Digital. Introducing the CHATTURAT-8.2, a powerful 8-channel equalizer DSP designed to elevate your car audio experience from Brazil to the world.

Versatile Features for Audiophiles:

Featuring 2 RCA inputs and 8 independent outputs, the CHATTURAT-8.2 offers routing channels and an input equalizer with 15 bands between 1/3 octave. Its parametric equalizer provides 3 independent bands per channel, and the crossover includes filters like Butterworth, Linkwitz-Riley, and Bessel, with attenuations from 6dB/8a to 48dB/8a.

Precision Control and Advanced Functions:

Experience precision with features such as independent delay per channel, automatic or manual limiter function with threshold, attack, and decay. Adjust input gain, utilize independent mute per channel, and enjoy a pink-noise generator for calibration. The unit is user-friendly with a user-controlled password and comes preconfigured out of the box.

Features for CHATTURAT-8.2:

• 2 RCA Inputs


• 8 Independent Outputs


• Routing Channels


• Input Equalizer with 15 bands between 1/3 octave


• Parametric equalizer with 3 independent bands per channel


• Crossover with filters: Butterworth, Linkwitz-Riley and Bessel, with attenuations from 6dB/8a to 48dB/8a


• Independent delay per channel


• Automatic or manual Limiter function with Threshold, Attack, and Decay


• Polarity Inversion


• Input gain adjustable


• Independent Mute per channel


• Pink-Noise Generator


• Independent Output gain per channel

Technical Specifications for CHATTURAT-8.2:

Inputs:

• Kind: Unbalanced


• Connection: RCA


• Input Max Level: 4Vpp (1.4Vrms)


• Input impedance: 47k

Outputs:

• Kind: Unbalanced


• Connection: RCA


• Input Max Level: 10Vpp (3.5 Vrms)


• Input impedance: 470


• Resolution: 24 Bits


• Sample Frequency: 48 Khz


• Latency Frequency: 1.08ms


• Range Frequency: 15Hz ~ 22KHz (-1db)


• THD+N max: 0,01%


• Signal to Noise Ratio: 100dB

Power Supply

• Voltage: 10 ~15V DC


• Consumption: 300mA (5w)


• Fuse: 2A

Item Dimensions

• (LxWxH): (10"x5"x1.25")
